DB DRIVESKU: X-A4002

A bridgeable two-channel Class D amplifier rated 75W x 2 at 4 ohms, compact enough for modern vehicles with tight install space.

Price:
$300.00

Description

  • Bridgeable to a single channel to run a subwoofer
  • High-efficiency Class D circuit for modern electrical systems
  • Adaptive high-pass and low-pass crossover for fine tuning
  • 4-layer PCB for cleaner, more accurate sound
  • Variable bass boost up to 12dB
  • Compact chassis for easy installation
  • Total dynamic power output: 300W
  • 2 x 75W @ 4 ohm stereo
  • 2 x 150W @ 2 ohm stereo
  • 1 x 300W @ 4 ohm bridged
  • Frequency response: 20Hz-20kHz
  • Input sensitivity: 0.2V-6V
  • Input impedance: 10K
  • Signal to noise ratio: 90dB
  • Variable filter: 30Hz-320Hz
  • Variable bass boost: 0-12dB

No downloads available for this product yet.

1 Year Standard Warranty
