DB DRIVE AMP X-SERIES 4CH CLASS D RMS 75W X 4 @ 4OHM / 150W X 4 @ 2 OHM

DB DRIVESKU: X-A4004

A four-channel Class D amplifier rated 75W x 4 at 4 ohms, bridgeable to two channels for a front-plus-sub or full-range install.

Price:
$396.00

Description

  • Four channels for a full front and rear speaker upgrade
  • Bridgeable to two channels to add a subwoofer
  • High-efficiency Class D circuit for modern electrical systems
  • Independent high-pass and low-pass crossovers
  • 4-layer PCB for cleaner, more accurate sound
  • Compact chassis for easy installation
  • Total dynamic power output: 600W
  • 4 x 75W @ 4 ohm stereo
  • 4 x 150W @ 2 ohm stereo
  • 2 x 300W @ 4 ohm bridged
  • Frequency response: 20Hz-20kHz
  • Gain level control: 0.2-6V
  • Input impedance: 10K
  • Signal to noise ratio: 90dB
  • High pass filter: 30Hz-320Hz
  • Low pass filter: 30Hz-320Hz
  • Variable bass boost: 0-12dB

No downloads available for this product yet.

1 Year Standard Warranty
